Printed Circuit Board Layout
CDC offers an experienced team of senior designers with the background and knowledge to ensure a properly functioning “quiet” printed circuit board to meet military, industrial and automotive challenges.
Multi-layer digital and analog, impedance control and high-speed designs are a few examples of the types of technologies addressed on a daily basis.
Ultra quick-turn layout available! We can offer 16-20 hours per day on a single layout.
Items required for a quick quote:
- Bill of Materials (excel format preferred)
- Netlist (any format)
- Schematic (pdf preferred)
- Mechanical considerations:
- Board size
- Connector placement
- Thermal considerations
- Special routing information:
- Differential pairs
- Impedance control
- Length matching
- Proposed layer count if known
- Board name and number
Additional Services Offered
Reverse Engineering:
We can perform a complete conversion of gerber data to an intelligent database. Submit your gerber data and we’ll convert it into the database format of your choice. Once the database is established, DRC’s can be performed and a variety of outputs can be generated.
Manufacturing & Assembly:
Let us provide the complete package from design through assembly. We work closely with select vendors in both manufacturing and assembly to ensure a quality product!
Compliance Review:
Our compliance review services help ensure designs, systems, and implementations align with applicable industry standards, regulatory requirements, and best-practice engineering guidelines. As part of our broader engineering and technical services offering, compliance reviews are conducted to identify potential risks, gaps, and inefficiencies early—reducing costly rework and accelerating time to market.
